Description

ADS1118 16-bit ADC Breakout Board

Features

• Ultrasmall X2QFN Package:
  2 mm × 1.5 mm × 0.4 mm
• Wide Supply Range: 2 V to 5.5 V
• Low Current Consumption:
  • Continuous Mode: Only 150 µA
  • Single-Shot Mode: Automatic Power Down
• Programmable Data Rate:
  8 SPS to 860 SPS
• Single-Cycle Settling
• Internal Low-Drift Voltage Reference
• Internal Temperature Sensor:
  0.5°C (Maximum) Error: 0°C to 70°C
• Internal Oscillator
• Internal PGA
• Four Single-Ended or Two Differential Inputs

More information:

• Download datasheet (pdf)
• Arduino library
• Raspberry Pi and python
