SIT1040T High-Speed CAN Transceiver SMD SOP8

Description

DESCRIPTION

The SIT1040 isthe interface between the Controller Area Network (CAN) protocol controller and the physical bus. It is primarily intended for high speed applications, up to 1 MBaud, in passenger cars. The device provides differential transmit capability to the bus anddifferential receive capability to the CANcontroller.

FEATURES:

Fully compatible with the ISO 11898 standard

Thermally protected

Input levels compatible with 3.3 V and 5 V devices

Transmit Data (TXD) dominant time-out function

Very low-current standby mode with remote wake-up Capability via the bus: 5μA Typical

Transceiver in unpowered state disengages from the bus (zero load)

At least 110 nodes can be connected

High speed (up to 1 MBaud)

Very low Electro Magnetic Emission (EME)

Datasheet
