ULTRA UR12V-9AH LEAD-ACID BATTERY

Description

THIS IS A RECHARGEABLE SEALED LEAD-ACID BATTERY.

Technical Specifications :

-General Information :

Model: 9A
Brand: ULTRA
Design Life: 10 Years
Weight: Approx. 2.7 kg
Terminal Type: F1 or F2 (Faston Tab 187 or 250)
Case Material (Option): UL94 HB / UL94 V-

-Dimensions :

• Length: 151 ±1 mm (5.94 ±0.04 in)

• Width: 65 ±1 mm (2.56 ±0.04 in)

• Height: 94 ±1 mm (3.70 ±0.04 in)

• Overall Height: 102 ±1 mm (4.02 ±0.04 in)

-Electrical Specifications :

Nominal Capacity :

• 20 Hour Rate (0.45A to 10.2V): 9.00 Ah

• 10 Hour Rate (0.852A to 10.2V): 8.41 Ah

• 5 Hour Rate (1.46A to 10.2V): 7.30 Ah

High Rate Discharge :

• 1C (9A to 9.60V): 5.70 Ah

• 3C (27A to 9.60V): 3.60 Ah

• 15-minute rate: 36W/cell to 1.60V/cell

Maximum Values :

• Maximum Discharge Current (5 sec): 135A

• Maximum Charging Current: 2.7A

• Internal Resistance (at 1KHz): Approx. 14 mΩ

-Charging Instructions (at 25°C / 77°F) :

Cycle Use

• Charging Voltage: 14.4V – 15.0V

• Temperature Compensation: -5.0mV/°C/cell

Standby (Float) Use

• Float Voltage: 13.5V – 13.8V

• Temperature Compensation: -3.0mV/°C/cell

-Operating Temperature Range :

• Charge: -15°C to 40°C (5°F to 104°F)

• Discharge: -15°C to 50°C (5°F to 122°F)

• Storage: -15°C to 40°C (5°F to 104°F)

-Charge Retention (Shelf Life at 20°C / 68°F):

• 1 Month: 92%

• 3 Months: 90%

• 6 Months: 80%

-Service Life :

Cycle Service Life Conditions :

1. Discharge: 5HR rate (0.17CA)

2. Charge: Constant Voltage 2.4V/cell for 16 hours, Imax 0.3CA

3. End of discharge voltage: 1.65V per cell

4. Temperature: 25 ±2°C

• 100% Depth of Discharge

• 50% Depth of Discharge

• 30% Depth of Discharge

Float (Trickle) Service Life :

Service life varies depending on ambient temperature.

-Compliance :

• ISO 9001 Certified

• Version No.: B-20240001

• This is a Dutch brand
