Name: UT705 Single Function Loop Calibrator
SKU: MT-STORE
Price: 15623.000 EGP
Availability: OutOfStock

Description

UT705 Single Function Loop Calibrator

this is a Single Function Loop Calibrator

Features of UT705 Single Function Loop Calibrator

Certifications: CE, UKCA

● Automatic ramp for DC current output

● Manual/automatic stepping and ramping output

● Stores and recalls setups

● Measures: DC voltage, DC current, 4-20mA loop current

● Output functions: DC current, analog transmitter, 24V loop

● Up to 0.02% accuracy current measurement at same time

Specifications	Range	UT705
Measure accuracy
DC voltage (V)	30.000V	±(0.02+2)
DC current (A)	24.000mA	±(0.02+2)
Loop current	24.000mA	±(0.02+2)
Source accuracy
DC current (source)	24.000mA	±(0.02+2)
DC current (simulate)	24.000mA	±(0.02+2)
Features
Loop power function	Voltage: 24V
	Accuracy: 10%
Ramp functions	Source functions: Voltage, resistance, temperature
	Ramps: Slow ramp, fast ramp, 25% step-ramp
Step functions	Source functions: Voltage, resistance, temperature
	Steps: 25% of range, 100% of range
General Characteristics
Power	9V battery (6F22)
Display	63mm x 40mm
Product color	Red and grey
Product net weight	410g
Product size	96mm x 193mm x 47mm
Standard accessories	Test leads, battery
Standard individual packing	Gift box, English manual, cloth bag
Standard quantity per carton	5pcs
Standard carton measurement	325mm x 225mm x 285mm
Standard carton gross weight	4.5kg

FOR MORE PRODUCTS LIKE THIS PLEASE CLICK HERE

Weight	4.5 kg
