XH2.54 XH-TJC3 XH-T 2.54mm Connector Terminals pins Pack of 80pcs

Description

XH2.54 XH-TJC3 XH-T 2.54mm Connector Terminals pins Pack of 80pcs

The XH2.54 XH-TJC3 XH-T 2.54mm Connector Terminals are commonly used crimp-style wire-to-board connectors designed for reliable electrical connections in various electronic applications.

Specifications:

• Connector Type: XH Series, Wire-to-Board Connector
• Pin Pitch: 2.54mm (0.1 inch)
• Material: Phosphor bronze (pins), Nylon (housing)
• Mounting Type: Through-hole / PCB mount
• Pin Configuration: Single-row
• Current Rating: Up to 3A per pin
• Voltage Rating: 250V AC/DC
• Contact Resistance: ≤ 20mΩ
• Insulation Resistance: ≥ 1000MΩ
• Withstand Voltage: 1000V AC/min
• Operating Temperature: -25°C to 85°C
• Pack Quantity: 80 pieces

Features & Benefits:

✅ Standard 2.54mm pitch → Compatible with many PCBs, breadboards, and Arduino modules
✅ Crimp-style connectors → Secure and easy-to-use wire connections
✅ Reliable electrical contact → Low resistance for better conductivity
✅ Nylon housing → Durable and heat-resistant
✅ Versatile Applications → Suitable for signal and power connections

Common Applications:

🔹 Arduino & Raspberry Pi Projects
🔹 Robotics & DIY Electronics
🔹 LED Strip & Power Connections
🔹 Battery Packs & Sensor Modules
🔹 General PCB Wire Terminations
