Specification Fluke 1555
|
|
Insulation resistance
|
Test voltage (dc)
|
Range
|
Accuracy (± reading)
|
|
250 V
|
< 200 kΩ
200 kΩ to 5 GΩ
5 GΩ to 50 GΩ
>50 GΩ
|
unspecified
5 %
20 %
unspecified
|
|
500 V
|
< 200 kΩ
200 kΩ to 10 GΩ
10 GΩ to 100 GΩ
>100 GΩ
|
unspecified
5 %
20 %
unspecified
|
|
1000 V
|
< 200 kΩ
200 kΩ to 20 GΩ
20 GΩ to 200 GΩ
>200 GΩ
|
unspecified
5 %
20 %
unspecified
|
|
2500 V
|
< 200 kΩ
200 kΩ to 50 GΩ
50 GΩ to 500 GΩ
>500 GΩ
|
unspecified
5 %
20 %
unspecified
|
|
5000 V
|
< 200 kΩ
200 kΩ to 100 GΩ
100 GΩ to 1 TΩ
>1 TΩ
|
unspecified
5 %
20 %
unspecified
|
|
10000 V
|
< 200 kΩ
200 kΩ to 200 GΩ
200 GΩ to 2 TΩ
>2 TΩ
|
unspecified
5 %
20 %
unspecified
|
|
Bar graph range
|
0 to 1 TΩ
|
|
Insulation test voltage
accuracy
|
-0 %, +10 % at 1 mA load current
|
|
Induced ac mains current
rejection
|
2 mA maximum
|
|
Charging rate for
capacitive load
|
5 seconds per μF
|
|
Discharge rate for
capacitive load
|
1.5 s/μF
|
| |
Range
|
Accuracy
|
|
Leakage current
|
1 nA to 2 mA
|
± (5 % + 2 nA)
|
|
Capacitance
|
0.01 uF to 15.00 μF
|
± (15 % rdg + 0.03 μF)
|
| |
Range
|
Resolution
|
|
Timer
|
0 to 99 minutes
|
Setting: 1 minute. Indication: 1 second
|
| |
Warning range
|
Voltage accuracy
|
|
Live circuit warning
|
30 V to 660 V ac/dc,
50/60 Hz
|
± (15 % + 2 V)
|
|
Display
|
75 mm x 105 mm
|
|
Power
|
12 V lead-acid rechargeable battery, Yuasa NP2.8-12
|
|
Charger Input (AC)
|
85 V ac 50/60 Hz 20 VA
|
|
Dimensions
|
269 mm x 277 mm x 160 mm (10.6 in x 10.9 in x 6.3 in)
|
|
Weight
|
3.7 kg (8.2 lb)
|
|
Temperature (operating)
|
-20 ºC to 50 ºC (-4 ºF to 122 ºF)
|
|
Temperature (storage)
|
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
|
|
Humidity
|
80 % to 31 ºC decreasing linearly to 50 % at 50 ºC
|
|
Altitude
|
2000 m
|
|
Enclosure sealing
|
IP40
|
|
Input overload protection
|
1000 V ac
|
|
Electromagnetic compatibility
|
EN 61326
|
