Isolated DC DC Power Supply B0503S-1WR3

SKU: d25-13-22
In Stock
EGP 125.000 exc. vat
In Stock

Other people want this. 1 people have this in their carts right now.
SKU: d25-13-22 Categories: ,

Isolated DC DC Power Supply B0503S-1WR3


B0503S-1WR3 Specifications:

  • Type: DC-DC Converter
  • Model: B0503S-1WR3
  • Package: SIP-4 (Single Inline Package, 4 pins)

Electrical Specifications:

  • Input Voltage Range: 4.5V to 5.5V (nominal 5V)
  • Output Voltage: 3.3V
  • Output Current: 303mA
  • Output Power: 1W
  • Efficiency: Up to 72%
  • Ripple & Noise: 100mVp-p (maximum)
  • Line Regulation: ±0.25%/V (maximum)
  • Load Regulation: 15% (maximum)
  • Isolation Voltage: 1000VDC (1 minute)
  • Switching Frequency: 100kHz (typical)

Environmental Specifications:

  • Operating Temperature Range: -40°C to +85°C
  • Storage Temperature Range: -55°C to +125°C
  • Humidity: 95% RH (non-condensing)

Physical Specifications:

  • Dimensions: 19.5mm x 6.0mm x 10.0mm
  • Weight: 4.2g (approximate)


  • High Efficiency: Up to 72% efficient for energy-saving operation.
  • Compact Size: Small SIP-7 package for space-constrained applications.
  • Wide Operating Temperature: Suitable for harsh environmental conditions.
  • Isolation Voltage: 1000VDC isolation ensures safe operation and noise reduction.
  • Overload Protection: Safeguards against output overcurrent conditions.
  • Continuous Short Circuit Protection: Protects the module and application in the event of a short circuit.


  • Industrial Control Systems
  • Distributed Power Supply Architectures
  • Telecommunication Equipment
  • Battery-Powered Devices
  • IoT Devices
  • Data Communication Systems


  1. Power Input: Connect the input voltage (4.5V to 5.5V) to the input pins.
  2. Output Connection: Connect the desired load to the output pins.
  3. Isolation: Ensure proper isolation in applications requiring noise reduction and safety compliance.
  4. Mounting: Integrate the SIP-4 package into the PCB layout for secure and efficient operation.

Ensure to handle and design circuits with the B0503S-1WR3 according to the manufacturer’s guidelines to achieve optimal performance and reliability.
