A basic accuracy of the output of up to 0.02% , the output is displayed as 6 -bit
2 output function:
DC voltage, DC current, ohms, analog transmitters, thermocouple, RTD, frequency, pulse, switch
3 DC current output, can provide 25% and 100% of the manual step, auto step and auto ramp output function
4 thermocouple output, can provide high-precision automatic cold junction compensation, ° C or ℉ temperature display
5 can be outside with high-precision temperature probe, accuracy: ± 0.2 ° C
6 large-screen LCD display multiple data can be displayed simultaneously: DC current and % values, thermocouple, temperature and thermal resistance values corresponding indexing, etc.
7 operational performance superior keyboard layout, increase or decrease output setting keys and LCD display set value on the corresponding bit
8 using the panel calibration techniques, without opening the chassis can be calibrated
9 with white LED backlight, and automatic backlight off and auto power off function, suitable for field use
Output of basic technical indicators [ apply within one year after calibration, 23 ° C ± 5 ° C , 35 ~ 70% RH , accuracy = ± (set value % + range % ) ]
Technology | art | means | Standard | output function
Function
Range
Output Range
Resolution
Accuracy
PreparationNotes
DC voltage
DCV
100mV
-10.000 ~ 110.000mV
1μV
0.02 + 0.01
Maximum output current 0.5mA
1000mV
-100.00 ~ 1100.00mV
10μV
0.02 + 0.01
Maximum output current 2mA
10V
-1.0000 ~ 11.0000V
0.1mV
0.02 + 0.01
Maximum output current 5mA
DC Current
DCmA
20mA
0.000 ~ 22.000mA
1μA
<
Additional information
Weight
0.42 kg
Brand
Chinese
Chinese
Chinese
