AC Digital Clamp Meter KYORITSU 2002R

AC Digital Clamp Meter KYORITSU 2002R Specs:

AC A	400A (0 – 400A) ±1.5%rdg±3dgt [45 – 65Hz] ±2.5%rdg±3dgt [40Hz – 1kHz]2000A (0 – 1500A) ±2%rdg±5dgt [45 – 65Hz] ±3%rdg±5dgt [40Hz – 1kHz]2000A (1500 – 2000A) ±4%rdg [50/60Hz]
AC V	40/400/750V ±1%rdg±2dgt [45 – 65Hz] ±1.5%rdg±3dgt [40Hz – 1kHz]
DC V	40/400/1000V ±1%rdg±2dgt
Ω	400Ω/4/40/400kΩ ±1.5%rdg±2dgt
Continuity buzzer	Buzzer sounds below 50±35Ω
Conductor size	φ55mm max.
Frequency response	40Hz – 1kHz
Output	Recorder : DC400mV against AC400A DC200mV against AC2000A
Safety Standard	IEC 61010-1 CAT III 600V / CAT II 1000V IEC 61010-2-031 IEC 61010-2-032
Power source	R6 (AA) (1.5V) × 2
Dimension	247(L) × 105(W) × 49(D)mm
Weight	Approx. 470g
Accessories	7107A (Test leads) 9094 (Carrying Case) R6 (AA) × 2 Instruction Manual
Optional Accessories	7256 (Output cord)

Name: AC Digital Clamp Meter KYORITSU 2002R
SKU: AB-ST-KEW 2002R
Price: 12027.000 EGP
Availability: OutOfStock

KYORITSU brand
