Iboard is a unique Arduino board which features a WIZnet ethernet port, an XBee socket, nRF24L01+ module interface and an ATMega328. This board will add wireless XBee / nRF24L01+ control as well as internet connectivity to your projects. It’s great for anything from home automation to robot control. The possibilities are endless!
Iboard can be used as an Ethernet, wireless communication project development platform. Iboard support POE (power on Ethernet) power supply, and Micro SD for mass storage. There are some 3pin electronic brick/ sensor brick interface breakout on board, it offer an easy way for a quick prototyping. You can setup a web server through which you may communicate with a remote Arduino using XBee radios, bluetooth or APC modules. This information can be posted to a web site, or to Twitter.
The board requires FTDI compatible module to download the sketch programs. Iboard can be powered by a mini USB , power Jack or POE.
|PCB size||79.2mm X 53.8mm X 1.6mm|
|Power supply||6-23V DC|
|Indicators||PWR, Tx, Rx, COL, FDX, SPD, LINK|
|Input Voltage VH (Target Voltage = 3.3V)||3||3.3||3.6||V|
|Input Voltage VL:||-0.3||0||0.5||V|
Top View Map
Iboard can be used as an Ethernet, wireless communication project development platform. Iboard support POE (power on Ethernet) power supply, and Micro SD for mass storage. There are some 3pin electronic brick/ sensor brick interface breakout on board, it offer an easy way for a quick prototyping.
Iboard is designed for compatible for SD and Wiznet libraries of Arduino, and all demo codes could be downloaded directly here:https://www.ladyada.net/learn/arduino/ethfiles.html
With embedded bootloader, Iboard is easy to use by Arduino IDE through any USB->UART modules
Datasheet for iBoard
Demo Code for iBoard
Schematic for iBoard
Fritzing Parts for iBoard
By michu <Make StripInvaders Cheaper: Use An IBoard>
Andy Karpov’s GitHub Page <RF24 library that supports nRF24L01 on iBoard>
Andy Karpov’s GitHub Page <RF24Network library that supports nRF24L01 on iBoard>
By NI$HANT <IBoard not able to access A6 and A7>
<BTBee Pro Wireless Program Tutorials>
<Fritzing Parts: ITEAD Development Board>
