ESP32CAM multifunction Programmer Module

Description

ESP32CAM multifunction Programmer Module

The programmer  is a simple ESP32-Cam programmer that adds the missing USB programming capabilities to the widespread EPS32-based camera microcontroller. ESP32 CAM USB Programmer  implements also the boot mode selection overcoming the missing reset pin by cutting off power to the microcontroller. This simplifies the programming of the cam module significantly since no manual reset and boot mode selection is needed when using a common USB to the serial interface.
The cam programmer board uses the popular CH340 serial USB chip and includes the ability to program the ESP32-Cam from the Arduino IDE using the ESP32 board definitions — something that was missing from the ESP32-Cam at launch. This C Type of USB programmer works like a shield that you attach to the ESP32-CAM board. The programmer comes with a USB socket that you connect directly to your computer. This product is known as Ai-Thinker Cam Board programmer, ESP Cam Board Programmer, ESP32 Cam Programmer, ESP32 Camera Board Programmer, etc.

Features/Specs:

• Serial Chip: CH340C
• Button: Boot, EN/RST
• Interface: USB for Programing , all GPIO for breakout the module connections
• USB Connector: C Type
• Female Connector for ESP32 Cam Board
• On Board Power ON Led
• Input Voltage: 5V
• Operating Temperature: -20~85°C
• Plugin Play
• Original Board made by UGE Electronics

Usage:

• Easy Programming: Connect the ESP32-CAM module, press the BOOT button, and upload your code via USB using your preferred IDE (Arduino IDE, PlatformIO, etc.).
• Versatile Interface: Use the 6-pin header to program other ESP modules directly or on the board.
• GPIO Expansion: Conveniently access and use all GPIO pins for external sensors, actuators, or modules.

This board is ideal for IoT development, rapid prototyping, and camera-based projects with the ESP32-CAM.
