RP2350A Raspberry Pi Pico2 chip microcontroller QFN60 7x7mm

Description

RP2350A Raspberry Pi Pico2 chip microcontroller QFN60 7x7mm

The RP2350A is a high-performance, secure microcontroller developed by Raspberry Pi, featuring a unique dual-core and dual-architecture design. Below are its key specifications:

Key Specifications:

• Processor Cores:
  • Dual-core architecture:
    • Two Arm Cortex-M33 cores operating at up to 150 MHz.
    • Two Hazard3 RISC-V cores operating at up to 150 MHz.
• Memory:
  • SRAM: 512 KB.
  • Flash: External QSPI flash support.
• Operating Voltage:
  • Core voltage: 1.1V.
  • I/O voltage: 1.8V to 3.3V.
• Peripherals:
  • USB 2.0 Host/Device.
  • UART, SPI, I2C interfaces.
  • PWM channels.
  • ADC and DAC.
  • GPIO pins.
• Security Features:
  • TrustZone support.
  • Cryptographic accelerators.
  • Secure boot.
• Package:
  • QFN-60 (7×7 mm).
• Operating Temperature Range:
  • -40°C to +85°C.

For detailed information, refer to the RP2350 Datasheet.and Raspberry Pi Datasheets
