Name: XC6206P302MR 250mA Fixed 3V Positive LDO Regulator SOT23
SKU: D17-11-XC6206P302MR
Price: 7.000 EGP
Availability: InStock

XC6206P302MR 250mA Fixed 3V Positive LDO Regulator SOT23

Model: XC6206P302MR

SKU: D17-11-XC6206P302MR

In Stock

EGP 7.000

In Stock

Electrical Characteristics:

Input Voltage Range: 1.8V to 6.0V
Output Voltage: Fixed at 3.0V
Maximum Output Current: 200mA
Dropout Voltage: Typically 250mV at 200mA load
Quiescent Current: Typically 8µA
Output Voltage Accuracy: ±2%

Description

XC6206P302MR 250mA Fixed 3V Positive LDO Regulator SOT23

The XC6206P302MR is a low-dropout (LDO) linear voltage regulator from Torex Semiconductor, designed to provide a stable 3.0V output suitable for various electronic applications. Below are its key specifications:

Features:

Compatible with low Equivalent Series Resistance (ESR) capacitors
Integrated current limiter to protect against overcurrent conditions
Thermal shutdown protection to prevent overheating
High ripple rejection ratio, typically 40dB at 1kHz

Package: SOT-23-3 (3-pin)

These features make the XC6206P302MR suitable for applications requiring a reliable and efficient 3.0V power supply, such as battery-powered devices and portable electronics. product.torexsemi.com
